Trijicon RMR footprint standarts
Footprint saderība izskaidrota
Ko nozīmē “footprint”? Termins footprint attiecas uz ligzdu un skrūvju caurumu struktūru optiskās ierīces pamatnē.
Un ko nozīmē, ja footprint ir saderīgi? Katram optiskajam tēmēklim ir kāda montāžas pamatne. Pamatne sastāv no tapām dažādās pozīcijās un skrūvju caurumiem, ko izmanto tēmēkļa fiksēšanai pie stiprinājuma.
Ja jebkuri divi tēmēkļi izmanto vienu un to pašu montāžas pamatni, mēs sakām, ka tiem ir vienāds footprint. Šajā rakstā parādām, kuri kolimatori izmanto vienu un to pašu footprint.
Trijicon RMR footprint raksts
RMR footprint sastāv no divām ligzdām priekšpusē un diviem skrūvju caurumiem tēmēkļa vidū.
Priekšējās ligzdas atrodas 22,5mm / 0.89 collas attālumā viena no otras, katra novietota tēmēkļa priekšējās daļas stūrī. Šo divu ligzdu novietojums atbilst tapu novietojumam uz jebkura šī standarta stiprinājuma montāžas virsmas.
Skrūvju caurumi atrodas aptuveni optiskās ierīces vidū. Tie kalpo tēmēkļa fiksēšanai pie stiprinājuma. Šie divi skrūvju caurumi atrodas 18,8mm / 0.74 collas attālumā viens no otra.
Skrūves, kas paredzētas šiem skrūvju caurumiem, vienmēr ir iekļautas komplektā ar tēmēkli.
Kolimatori ar Trijicon RMR footprint
Skatīt visu-
-
Vector Optics Frenzy 1x22x26 MOS MRS kolimators
€159,00 EURVienības cena /Nav pieejamsIr noliktavā -
-
-
Izpārdots€520,00 EURVienības cena /Nav pieejams
-
-
-
![Osight C [sarkans]](http://lv.optics-spot.eu/cdn/shop/files/Osight_C_red_dot_sight.jpg?v=1767038233&width=460)
![Holosun 507 Comp [sarkans]](http://lv.optics-spot.eu/cdn/shop/files/Holosun_507_Comp_red.jpg?v=1767037013&width=460)
![Holosun 507 Comp [zaļš]](http://lv.optics-spot.eu/cdn/shop/files/Holosun_507Comp_green.jpg?v=1767037263&width=460)
![Osight X [sarkans]](http://lv.optics-spot.eu/cdn/shop/files/Osight_X_red.jpg?v=1767039569&width=460)
![Holosun 507C X2 [sarkans]](http://lv.optics-spot.eu/cdn/shop/files/Holosun_507C_red.jpg?v=1767038950&width=460)
